Connect with your audience 24/7
With the future proof Smart Collection
With this high brightness Signage Solution display, you will enjoy all the benefits of state-of-the-art connectivity and content Imanagement possibilities while being ensured that remote management safeguards the lowest cost of ownership
Optimized for public viewing
High brightness for clearer images -
IPS wide view technology for image and color accuracy -
Designed for 24/7 operation -
Maximizing the impact of your message
Colour Calibration kit to ensure uniform colours
Innovative solutions for any signage application
Save and play content with internal memory -
Free and easy-to-use content management with SmartCMS -
Connect and control your content via the cloud with HTML5 -
Schedule what you want, when you want with SmartPlayer -
Optional OPS Insert to create an all-in-one solution -
Care about you, your business and your audience
Keep your content up and running with FailOver -
Clinical D-image preset for DICOM part 14 Grayscale images -
Specifications
Picture/Display
Diagonal screen size: 42.02 inch / 106.73 cm -
Panel resolution: 1920x1080p -
Optimum resolution: 1920 x 1080 @ 60Hz -
Brightness: 700 cd/m² -
Contrast ratio (typical): 1300:1 -
Dynamic contrast ratio: 500,000:1 -
Aspect ratio: 16:9 -
Response time (typical): 8 ms -
Pixel pitch: 0.4833 x 0.4833 mm -
BDL4290VL/00
| Video formats | Sound | ||
| Resolution | Refresh rate | Built-in speakers: 2 x 10W | |
| 1080p | 50, 60Hz | Multimedia Applications | |
| 1080i | 50, 60Hz | ||
| 720p | 50, 60Hz | USB Playback Audio: AAC, AIF, AIFF, ASF, LPCM, | |
| 576i | 50Hz | M3U, M4A, MP3, MP4, WAV, WMA | |
| 576p | 50Hz | USB Playback Picture: BMP, GIF, JPEG, JPG | |
| 480p | 60Hz | • USB Playback Video: M2TS, M4V, MK3D, MKV, MP4, | |
| 480i | 60Hz | MPEG, MPG, MTS, TS, TTS, VOB, WMV |
Display colors: 1.07 billion -
Viewing angle (H / V): 178 / 178 degree -
Picture enhancement: 3/2 - 2/2 motion pull down -
Motion compens. deinterlacing, Progressive scan,Dynamic contrast enhancement, 3D Combfilter, 3D
MA deinterlacing
Connectivity
(Video input: DisplayPort (1.2), HDMI (x2), DVI-D, VGA (Analog D-Sub), USB, Component (BNC x3), Composite (BNC
(Video output: DisplayPort, DVI-I, VGA (Analog D-Sub
(Audio input: 3.5 mm jack, Audio Left/Right (RCA
Audio output: Audio Left/Right (RCA), External speaker connector
Other connections: OPS, USB
External control: RJ45, RS232C (in/out) 2.5 mm jack, IR (in/out) 3.5 mm jack
Supported Display Resolution
Computer formats -
| Resolution | Refresh rate |
| 1920x 1200 | 60Hz |
| 1920x 1080 | 60Hz |
| 1600x 1200 | 60Hz |
| 1440x 900 | 60Hz |
| 1366x 768 | 60Hz |
| 1360x 768 | 60Hz |
| 1280x 1024 | 60Hz |
| 1280x 800 | 60Hz |
| 1280x 768 | 60Hz |
| 1024x 768 | 60Hz |
| 800x 600 | 56, 60, 72, 75Hz |
| 640x 480 | 60, 67, 72, 75Hz |
Dimensions
Bezel width: 6.5 mm
(Set dimensions (W x H x D
x 541.0 x 56.8 mm
(Set dimensions in inch (W x H x D
x 21.3 x 2.2 inch
Product weight: 15.3 kg
Product weight (lb): 33.7 lb
VESA Mount: 200 x 200 mm, M6
Convenience
Placement: Portrait, Landscape
Tiled Matrix: Up to 10 x 10
Keyboard control: Hidden, Lockable
Signal Loop Through: DVI, RS232, IR Loopthrough, VGA, DisplayPort
Network controllable: RS232, RJ45, HDMI (One Wire), Card OPS RS232, One Wire (HDMI-CEC)
Energy saving functions: Smart Power
Screen saving functions: Pixel Shift, Low Bright
Other convenience: Carrying handles
Memory: 16GB eMMC
Power
(.Consumption (On mode): 90 W (Typ
Standby power consumption: <0.4 W
Mains power: 100 ~ 240 VAC, 50 ~ 60 Hz
Operating conditions
Temperature range (operation): 0 ~ 40 °C
Temperature range (storage): -20 ~ 60 °C
Relative humidity: 20 ~ 80 %
Altitude: 0 ~ 3000 m
(MTBF: 60,000 hour(s
Accessories
Included accessories: Remote Control, Batteries for remote control, AC Power Cord, User manual on CD-ROM, Quick start guide, RS232 cable
(Stand: BM04642 or BM02542 (Optional
(Optional accessories: ColourCalibrationKit (CCK4601), HDBaseT OPS Receiver (CRD25
Miscellaneous
On-Screen Display Languages: English, French, German, Italian, Polish, Russian, Simplified Chinese, Spanish, Turkish, Arabic, Japanese, Traditional Chinese
Regulatory approvals: CB, CCC, CE, CECP, C-Tick, EPEAT, FCC, Class A, GOST, UL/cUL
Warranty: 3 year warranty
