PHILIPS INDUSTRIAL MONITOR-TOUCH FAMILY MODEL BDL5556ET

PHILIPS INDUSTRIAL MONITOR-TOUCH FAMILY MODEL BDL5556ET

Discover a new level of interaction

with this multi touch LED display



Get even closer to your audience than ever before. Fast, precise and extremely durable, its high performance is matched by excellent reliability and functionality.



Optimised for public viewing

  • Full HD LED for brilliant images with incredible contrast
  • Designed for 24/7 operation



Supreme audience interaction

  • Experience amazing interactivity with true Multi-Touch
  • Optical touch technology for advanced user interaction
  • True multi-touch with 6 simultaneous touch points
  • Compatible with all leading operating systems



Innovative solutions for any signage application

• Optional OPS Insert to create an all-in-one solution





Care about you, your business and your audience

• SmartPower for energy saving





Maximising the impact of your message

• Manage and control your network remotely via SmartControl





Specifications

Picture/Display  576p  50 Hz
Simplified Chinese, Traditional Chinese, Arabic,
• Diagonal screen size: 54.6 inch / 138.7 cm 576i 50 Hz Japanese
• Panel resolution: 1920 x 1080p 720p 50, 60 Hz • Regulatory approvals: CE, CCC, FCC, Class B, UL/
• Optimum resolution: 1920 x 1080 @ 60 Hz 1080i 50, 60 Hz cUL, RoHS, EPA, CB, C-Tick, EAC, EMF, KUCAS,SASO
• Brightness: 450 cd/m² 1080p 50, 60 Hz  • Warranty: 3-year warranty
• Contrast ratio (typical): 1300:1

480p

60 Hz
• Dynamic contrast ratio: 500,000:1 Convenience
• Response time (typical): 12 ms
• Aspect ratio: 16:9 • Placement: Landscape, Portrait
• Viewing Angle (H / V): 178 / 178 degree • Signal Loop Through: DVI, RS232, VGA
• Display colours: 1.06 Billion • Network controllable: RS232, RJ45
• Pixel pitch: 0.63 x 0.63 mm • Picture performance: Advanced colour control
• Surface treatment: Anti-Glare coating • Picture in picture: PIP
• Picture enhancement: 3/2 - 2/2 motion pull down, • Screen-saving functions: Pixel Shift, Low Brightness
3D Combfilter, Motion compens. deinterlacing, • Keyboard control: Hidden, Lockable
Progressive scan, 3D MA deinterlacing, Dynamic • Remote control signal: Lockable
contrast enhancement • Ease of installation: AC Out, Smart Insert
Interactivity • Energy-saving functions: Smart Power
• Packaging: Reusable box
• Multi-touch technology: Optical sensing • Other convenience: Carrying handles
• Touch points: 6 simultaneous touch points Dimensions
• Plug and play: HID compliant
• Protection glass: 5 mm tempered safety glass • Set dimensions (W x H x D):
Connectivity 1257.3 x 728.1 x 79 mm
• Bezel width: 19.5 mm
• Video input: DisplayPort (1.1a), HDMI, DVI-D, • Product weight: 43 kg
VGA (Analogue D-Sub), Component (RCA), • VESA Mount: 400 x 400 mm, 400 x 200 mm, 200 x
Composite (RCA) 200 mm
• Video output: DVI-I, VGA (via DVI-D) • Smart Insert mount: 100 x 200 mm, 100 x 100 mm
• Audio input: Audio Left/Right (RCA), 3.5-mm jack Sound
• Audio output: Audio Left/Right (RCA), External
speaker connector • Built-in speakers: 2 x 10 W
• External control: RJ45, RS232C (in/out) D-Sub9 Operating conditions
• Other connections: USB, AC-out, OPS
Supported Display Resolution • Temperature range (operation): 5 ~ 40 °C
• Relative humidity: 20 ~ 80 %
• Computer formats • MTBF: 50,000 hour(s)
Resolution Refresh rate Power
640 x 480 60, 67, 72, 75 Hz
800 x 600 56, 60, 72, 75 Hz • Mains power: 90 ~ 240 VAC, 50/60Hz
1024 x 768 60 Hz • Consumption (On mode): 140 W (Typ.)
1280 x 768 60 Hz • Standby power consumption: <0.5 W
1280 x 800 60 Hz Accessories
1280 x 1024 60 Hz
1360 x 768 60 Hz • Included accessories: AC Power Cord, VGA cable,
1366 x 768 60 Hz RS232 cable, USB cable, Remote Control, Batteries
1440 x 900 60 Hz for remote control, Quick start guide, User manual
1600 x 1200 60 Hz on CD-ROM
1920 x 1080 60 Hz • Stand: BM05462 (Optional)
1920 x 1200 60 Hz Miscellaneous



• Video formats
Resolution Refresh rate • On-Screen Display Languages: English, French,
480i 60 Hz German, Italian, Polish, Turkish, Spanish, Russian,
