ULTRA RESISTANT INDUSTRIAL LAPTOPS FAMILY MODEL FP10

ULTRA RESISTANT INDUSTRIAL LAPTOPS FAMILY MODEL FP10

Fully rugged and fully loaded



The FP10 gives you the rugged reliability you expect plus a wide array of high-performance functionality. It’s 17” HD screen, Intel i7 processor and up to 16GB of RAM make it ideal for viewing maps, running demanding apps and analyzing photo and video. And with a massive range of accessories and configuration possibilities, theFP10 lets you customize a solution that meets all your demands.



Built to take a beating

The FP10 is built from the ground up to withstand the harshest conditions over the long haul. It has a magnesium alloy casing, MIL connectors and is designed for operations down to -20 °C. This toughness has been proven on the ground time and time again with international combat forces.



Guaranteed performance

Our products always come with lifetime support to ensure your equipment maintains peak performance for many missions to comeFP10


Technical Specification

CPU Intel Sandy Bridge i7-2610UE
RAM Max 16 GB DDR3 1333 MHz
Graphic Intel HD Graphics 3000
Storage 160 GB – 500 GB SATA HDD / SSD
Display 17.1 " WXGA+ (1440 x 900) LED
Backlight 500 nits
Sound HD Audio and Stereo Speakers
Keyboard/mouse 87-Keyboard, Resistive touch pad
(PS/2)
Interfaces 1 x Flex Bay (HDD/DVD/Batt etc)
(right)
Interfaces 1 x PS/2
(left) 2 x USB 3.0**
1 x USB 2.0 fast charger
1 x IEEE1394a (Firewire)
1 x RJ45 LAN (10/100/1000mbps)
3 x 3.5mm (Mic,Line-in/earphone)
1 x PCIe slot
Interfaces 2 x Serial Port DB9
(rear) 1 x DC in 12-32V
1 x RGB DB15
1 x DVI
1 x Printer Port DB12
Interfaces 4 x mini PCIe (3x full-size / 1x half-size)
(internal) 4 x USB 2.0
4 x Serial (BIOS selectable:
RS232/RS422/RS485/TTL)
Primary Battery Removable 11,1 V / 8700 mAh Lithium-
Ion primary battery
Power Input DC 12 V- 32V
AC Adapter: 90W AC 100V~240V
50/60Hz
Case Magnesium alloy
Dimensions 412.4 x 318.2 x 77 mm (W x D x H, with
rubber bumpers)
Weight 5.9 kg (depending on configuration)
Certifications CE, FCC, WEEE, REACH, WHQL,
IP65 (without protection caps),
MIL-STD-810G* and MIL-STD-461F*
Operating System Windows 7, Windows 8
Linux – depending on configuration

*Contact MilDef for full specifications of MIL-STD-810G and MIL-STD-461F **Non-native USB 3.0
MIL-STD-810G Operating Storage
Altitude 4572 m (15000 ft) 12192 m (40000 ft)
Method 500.5,
(procedure I, II)
Temperature -20 °C to 55 °C -40 °C to 70 °C
Method 501.5 & 502.5, (-4 °F to 131 °F) (-40 °F to 158 °F)
(procedure I, II)
Temp Shock -20 °C to 60 °C -
Method 503.5 (-4 °F to 140 °F)
(procedure I)
Shock 40 G, 11 ms 40 G, 11 ms
Method 516.6, (procedure I) 122 cm (26 drops) 122 cm (26 drops)
Vibration OH58A/C -
Method 514.6, Helicopter and
(category 14 & 20) Composit wheeled
Vibration vehicle vibration
M548 Tracked -
Method 514.6, Vehicle
(category 1)
Rain 276 kPa, 5 -
Method 506.5, (procedure II) Surfaces, 40
Humidity min/Surface
- Ten 24 h test cycles
Method 507.5
Salt Fog - Salt 5 ±1 %, 24 h wet
Method 509.5, (procedure I) + 24 h dry/cycle. Total
2cycles / 96 h
Standard Options
Flex Bay / Storage Removable 3.5" DVD-RW 2nd SATA HDD with
heater or secondary battery. Flexbay with
DC, PCIe, USB, LAN, SATA and serial signals
for customer specific modules.
ViaSat® Eclypt® Core encrypted HDD/SSD
[Export Controlled]
Communications 10/100/1000Mbit LAN RJ45,
WLAN (a/b/g/n) / BT 4.0 (BLE)
WWAN/HSDPA, GPS
Additional 2 x MIL Connector upgrade for
Connectivity RS232/422/485 etc.
External COM3/4 RS232/422/485)
100 or 1000 base fibre LAN in LC, HMC or
Power HMA connector.
Built in vehicle adapter (12-32 V DC)
Mil connector upgrade for DC
Secondary battery 11.1V 7200 mAH
Lithium- Ion
Optional MIL-STD-1275B for DC input
Graphics NVIDIA GeForce GT520M
Display WUXGA 1920 x 1200
Night Vision
Keyboard 89-keys backlit keyboard,
Keyboard dust cover (for std keyboard)
MIL-STD-461F Ground Navy
