Create new stopping power

with Ultra Narrow Bezel displays

Impress your audience with the most impactful video wall. With ultra anarrow bezel and stunning picture quality, you are sure to create the most memorable visual experience

Optimized for public viewing

• Full HD LED technology for brilliant images
• IPS wide view technology for image and color accuracy
• Designed for 24/7 operation

Maximizing the impact of your message

• Immersive visual experience with Ultra Narrow Bezel
• Colour Calibration kit to ensure uniform colours

Innovative solutions for any signage application

• Optional OPS Insert to create an all-in-one solution
• Schedule what you want, when you want with SmartPlayer

Care about you, your business and your audience

• SmartPower for energy saving
• Keep your content up and running with FailOver

Specifications

Picture/Display

• Diagonal screen size: 48.5 inch / 123.2 cm
• Panel resolution: 1920x1080p
• Optimum resolution: 1920 x 1080 @ 60 Hz
• Brightness: 450 cd/m²
• Contrast ratio (typical): 1300:1
• Dynamic contrast ratio: 500,000:1
• Response time (typical): 8 ms
• Aspect ratio: 16:9
• Viewing angle (H / V): 178 / 178 degree
• Pixel pitch: 0.56 x 0.56 mm
• Display colors: 1073 M
• Picture enhancement: 3/2 - 2/2 motion pull down, 3D Combfilter, Motion compens. deinterlacing, Progressive scan, 3D MA deinterlacing, Dynamic contrast enhancement

Supported Display Resolution

• Computer formats

Connectivity

• Video input: DVI-D, HDMI (x2), VGA (Analog D-Sub), DisplayPort (1.2), Component (BNC x3),

Composite (BNC)

• Video output: DisplayPort, DVI-I, VGA (via DVI-I)
• Audio input: 3.5 mm jack, Audio Left/Right (RCA)
• Audio output: Audio Left/Right (RCA), External speaker connector
• External control: IR (in/out) 3.5 mm jack, RJ45, RS232C (in/out) 2.5 mm jack
• Other connections: OPS

Convenience

• Signal Loop Through: RS232, VGA, DisplayPort, DVI, IR Loopthrough
• Ease of installation: Carrying Handles
• Energy saving functions: Smart Power
• Network controllable: RS232, RJ45, Card OPS RS232, One Wire (HDMI-CEC)
• Placement: Portrait, Landscape
• Screen saving functions: Pixel Shift, Low Bright
• Tiled Matrix: Up to 10 x 10

Dimensions

• Bezel thickness: 3.5 mm
• Bezel width: Top/Left: 2.35mm, Bottom/Right: 1.25mm
• Set dimensions (W x H x D): 1077.6 x 607.8 x 103.8 mm
• Set dimensions in inch (W x H x D): 42.4 x 23.9 x 4.1 inch
• VESA Mount: 400 x 400 mm, M6
• Product weight: 21.6 kg
• Product weight (lb): 47.6 lb

Operating conditions

• Temperature range (operation): 0 ~ 40 °C
• Temperature range (storage): -20 ~ 60 °C
• Altitude: 0 ~ 3000 m
• Relative humidity: 20 ~ 80 %
• MTBF: 50,000 hour(s)

Power

• Consumption (On mode): 110 W (EnergyStar 6.0 test method)
• Standby power consumption: <0.5W

Sound

•   Built-in speakers: 2 x 10W (RMS)

Accessories

• Included accessories: Remote Control, Batteries for remote control, AC Power Cord, RS232 cable, User manual on CD-ROM, Quick start guide, Edge alignment pins, Edge alignment plates, DVI-D cable
• Optional accessories: Edge finishing kit, ColourCalibrationKit (CCK4601), HDBaseT OPS Receiver (CRD25), IR Light Motion Sensor (CRD41)

Miscellaneous

• On-Screen Display Languages: Arabic, Simplified Chinese, Traditional Chinese, English, French, German, Italian, Japanese, Polish, Russian, Spanish, Turkish
• Regulatory approvals: CE, FCC, Class B, UL/cUL,CB, GOST, EPEAT
• Warranty: 3 year warranty
